How to build our new Chassis DESTINY a 3Dprinted RC car Chassis?

The whole design is made for scale 1/10. This is our third 3rd generation self-developed Chassis.

From here on in, each upgrade will be available for all of our cars.  This means there will always be one up top super massive chassis for a car Body Kit with the latest developments and even more…

You can build a Chassis for any bodies (which only you have, we don’t) with Custom DESTINY.

New File Accessibility

There is only one Compressed file you need to download and you will have access to all Chassis variations, to all of our Body Kits and Custom DESTINY.

Here are the most important Changes/Upgrades

VARYING” parts (orange ones)

In the new downloadable WHOLE file package you will get main folders in which there are Constant/Base and so called “Varying” parts. With these changeable parts you are able to set any width and any desired length to the chassis.

Clicking on above button there is information about the latest features added!

The “Varying” parts:

The Wheelbase is adjusted by the Connecting part. Front and Rear Track are set/adjusted by all the others.

• Varying parts listed from left:
  1. Wheelnuts Rear Tamiya: Base-0mm/+1mm/+2mm/+3mm/+4mm
  2. Wheelnuts Rear 3Dprinted: Base-0mm/+1mm/+2mm/+3mm/+4mm
     • You have to choose which one to use: 1. or 2.
  3. DogBones: for the Rear Track in 7 sizes
  4. Rear Rocking Arms: for the Rear Track in 7 sizes
  5. Connecting Part: in 66 sizes (235mm-300mm Wheelbase)
  6. Steering Sides: in 7 sizes, 3 different versions for ball heads 4/4.8/5mm
  7. Front Rocking Arms: for the Front Track in 7 sizes
  8. Wheelnuts Front: Base 0mm/+1mm/+2mm/+3mm/+4mm
     Here the Wheelnut is also the front shaft.
  9. M3 Threaded Rods for Front and Rear Turnbuckles length set by You! Not on the picture.

Let’s take an example. You want to build a chassis having a Front or Rear track of 177mm. You need a Rocking Arm part 175mm and a Wheelnut +2mm.

All other parts (not the orange ones) will always be the same for all chassis versions!

Posts showing You with what parts to build DESTINY for our Body Kits:

• Ford Mustang 1967 Fastback
• BMW M3 GTR (e46)
• Peugeot 406 from Taxi2
• Dom’s Dodge Ice Charger from FF8
• Nissan GT-R r35 Liberty Walk Silhouette
• Porsche 911 GT2 (997)
• Lamborghini Aventador LP-700-4
• VolksWagen Golf mk.2

All of the fixing M2 screws changed to M3 ones.

The M2 screws were too tiny and weak. With the M3 ones the chassis is more stable and robust. The assembly time is being reduced thanks to one type of screw being used mostly everywhere.

Two exceptions had to be made where we had to use different sized Screws/Rods. One is in the middle at the Body Mounting part which has M4 threaded rods. We needed to have these one size bigger, because this section of the chassis takes up a lot of stress during “gaming” and has to withstand enormous forces.

The second exception is the DogBone. We used cut M2 screws for one of the most vulnerable section of this vital part. Some other kind of little metal material can also be used, like a nail.

3Dprinted DogBone with M2 rod

I really don’t know why we didn’t start with a 3Dprinted version at the very beginning.
“Why oh Why Mr. Anderson !?”
The engineer brother really did not have enough faith in printing this item. He feared would break after 10 meters the RC car made. Well, by now we have tested this multiple times and so far so good!

One thing is sure though, we highly recommend this to print with 100% infill! It will warp a little, but becomes as strong as it gets. The length of the cut M2 rod is 13mm.

Printed connectors to the Ballheads are now available in three different sizes

In DESTINY we are using 8 Ballheads. At the turnbuckles(4 pcs) and at the steering (4 pcs).

As it came to our senses, we realized that the three most common Ballheads in a 1/10 scale RC system are the 4mm/4,8mm/5mm. Now you have flexibility, if only one of the below ballhead pieces are available to obtain in your area. You choose which one to use! Just make sure the thread on it is M3.

Magnets fixing the body to the chassis

The mounting system has also been improved slightly since the last design. This solution quite works, so onward we will be fixing the rc body kit to the chassis with magnets (grey in the section views). The orange parts are glued to the rc car’s bodyshell.

Magnet Size: 8mm diameter, width 4 mm
All together 8pcs will be needed, 4 pieces at the frontal mounting and 4 in the middle. In the middle section there also the possibility to fix the body to the chassis with screws.

New Front Wheel Section

The new bearing is the same which is in use at the differential. Size: 10x15x4 mm.

The bearings are the two brown parts on the upcoming picture. The printed yellow shaft which is screwed together with a printed cap and the rim wheel holds the bearings. The red assembled printed part can rotate with the two M3x6m screw “axis”.

The turnbuckle (head attached with the orange ballcup) is changeable in length thanks to the rc car chassis specific grey M3 threaded rod.

The ballconnector head (on orange ballcup) comes in three different sizes just as the steering system sides: 4mm/4,8mm/5mm.

Rear bearing with two alternatives

The big bearing (10x15x4mm) is also available at the rear axle with printed parts (left side on next pic). We fixed the rim to the 3Dprinted shaft (light red) with M3x12 screw (blue). The yellow is the wheel adapter or wheelnut (hexagon).

If you choose the bigger bearing with 3Dprinted shaft you will stick to the one bearing being used through out the whole chassis building/assembly. When not applying the Tamiya wheel axle means another cost cut for you, around 10 bucks! But, of course it is still available to the chassis to be built with it!

“Ebay” Differential Inlet Shaft with 10x15x4 Bearings instead of 5x11x5

Changing this was because of the idea to make it possible to use only one type of bearing throughout the whole Rc car Chassis. This is why we created this new design. The yellow and the turquoise blue part are 3Dprinted, the two brown are the bearings.
For this variation there is also a new housing that holds this.

This bigger bearing will also be in use if you 3Dprint the whole Bevel Gear Set. Upcoming headline below.

3Dprinted Bevel Gears

3DPrint it in order to spare another 10 dollars from ebay! But you’ll not have a differential! This option is providing a simple direct drive bevel gear set, if you decide to incorporate.  Anyway, the number of teeth, the gear ratio and the size is the same.

In this case all the 4 bearings (brown on the picture) are the same size: 10x15x4 mm

Assembly steps:

• Place Bearings (brown) into both sides of the Housing (green).
• Put the Dogbone holder (nut version – butter white) into the bearing, then pull on the Driven Gear (red).
• Place the two Bearings on the Drive Gear (pink), after that you can screw it with the Clutch (turquoise blue) with an M3x25.
• Place the Drive Gear (pink) on the Driven Gear (red) inside the housing. After that, fix the two sides of the housing together.
• Click in the other Dogbone holder (bolt head version – yellow).
• Screw the Driven Gear (red) the two Dogbone holders together with an M3x25.
• Lastly, screw the housing together with four M3x10s.

Three different sizes of Rear Shock Absorber brackets. New Receiver and Controller Brackets.

1. Motor controller bracket, 2. Receiver bracket, 3. Rear shock absorber holder.

We designed those two brackets for the receiver and the controller. Attention! It will only work for the exact same type of devices. Check the sizes before printing if it’ll be good for you! Receiver bracket is 20x12mm. The Controller bracket is 30x36mm.

The Rear Shock Absorber bracket now is coming in three different sizes! The height of the fixing arch is changing for Rear Suspension hole to hole distance: 50mm/55mm/60mm. We did this in order to help You out, if you cannot find one kind of suspension in any shops near you. Now, there are two more options for you to build this chassis with. For the frontal suspension you will only need the spring. The spring holder both up and down are 3D prints so you can have the shortest Hole to Hole distance. This means any sports car which hood is extremely low can be built.

There is an important decision for YOU to make!

Buy or not Buy?

3D printing settings we used

3D Printer: Creality Ender 3 V2 NEO, Zortrax M200 plus
Technology: FDM
Used material: ABS filament
Slicer program: Zortrax Z-SUITE, Prusaslicer

Settings:
Infill: 20%
Recomended layer height: 0.19 mm
Support was set automatically by the program

Got a question about building Know-How?
Ask us on Facebook!

Don’t Miss the Next Project SUBSCRIBE on YouTube.

Most Used TOOLS

Scalpel&Allenkeys&RASPs

Scalpel for removing print support. Keys for screws. Every kind of Rasps to get the surface smooth and even.

Super glue

Both Gel and Liquid ones. Use GEL when putting parts together. When it holds use LIQUID on the surface.

Glue Gun

It’s adhesive sets very quickly. We used it only inside the body kit, because on the surface leaves nasty traces.

Full Assembly Video
